Double Color PVC Ceiling Printing and UV Coating Line

ANDA's PVC Ceiling Printing Machine combines two-color decorative printing and UV coating to produce high-quality surface finishes for PVC ceiling and wall panels.
Two-Color Printing: Creates wood-grain, marble-effect, and customized decorative patterns.
UV Coating: Supports glossy and matte finishes for different surface requirements.
High-Speed Production: Adjustable conveying speed up to 30 m/min.
Flexible Pattern Design: Interchangeable printing rollers for different decorative styles.
Stable Coating Control: Independently driven rollers for adjustable UV varnish application.
Customizable Configuration: Optional servo printing and machine configurations to suit production needs.
Availability:
Quantity:
  • China

  • JINSE

PVC Ceiling Panel Printing Machine for Decorative Surface Finishing

ANDA Machinery provides the Double Color PVC Ceiling Printing and UV Coating Line for decorative surface finishing of PVC ceiling panels, PVC wall panels, door boards, window sills, and other suitable flat panels.

The line combines two-color roller printing with UV varnish coating to create wood-grain, marble-effect, glossy, and matte decorative surfaces. Interchangeable printing cylinders allow manufacturers to develop different patterns, while adjustable coating rollers support different finishing requirements.

With a specified conveying speed of up to 30 m/min, the machine is designed for continuous panel surface processing.

Decorative Printing and Surface Finishing Applications

The printing and UV coating line is suitable for different decorative flat-panel products.

Finished Product

Surface Finishing

PVC Ceiling Panels

Wood-grain, marble-effect, and decorative pattern printing

PVC Wall Panels

Printed decorative surfaces with UV varnish

PVC Door Boards

Wood-effect and other decorative finishes

PVC Window Sills

Printed surface patterns and protective decorative coatings

Cabinet Boards

Customized patterns with glossy or matte finishes

Printing results depend on the substrate surface, ink, printing cylinder, and UV coating formulation.


Technical Specifications

Parameter

Model 600

Model 800

Printing Colors

2 Colors

2 Colors

Working Width

600 mm*

To Be Confirmed

Panel Thickness

5–80 mm

5–80 mm

Conveying Speed

0–30 m/min

0–30 m/min

Total Power

60 kW

75 kW

Machine Dimensions

32000 × 1700 × 1400 mm

32000 × 1700 × 1400 mm

Servo Printing

Optional

Optional

Printing Cylinders

Interchangeable

Interchangeable

UV Coating

Available

Available

The published working-width information should be verified with ANDA, particularly for Model 800. Actual production speed depends on panel dimensions, printing patterns, coating materials, and operating conditions.

Features and Benefits

Two-Color Decorative Pattern Printing

The printing system uses interchangeable cylinders to transfer wood-grain, marble-effect, and other decorative patterns onto PVC panels.

Manufacturers can expand their product collections by changing printing cylinders and ink colours without changing the underlying panel production process.

Adjustable UV Roller Coating

The UV coating section uses independently driven rollers, allowing operators to adjust coating conditions according to the varnish and required surface appearance.

This supports the production of different decorative finishes, including glossy and matte surfaces.

Continuous Production up to 30 m/min

The line integrates panel conveying, two-color printing, and UV coating into a continuous surface-finishing process.

Its adjustable conveying speed supports different panel specifications and production requirements.

Continuous Ink and Varnish Supply

Diaphragm pumps feed printing ink and UV varnish to the corresponding processing sections.

Collection grooves support recovery and recirculation of suitable excess materials, helping operators manage consumables during production.

Flexible Printing Pattern Changeover

Replaceable printing cylinders allow manufacturers to switch between different decorative patterns.

This is particularly useful for factories producing multiple wood-grain, marble-effect, and custom panel designs.

Optional Servo Printing Configuration

ANDA offers optional servo printing for projects requiring additional printing control.

The suitable configuration can be discussed according to the panel dimensions, decorative pattern, and production requirements.

Main Components of the PVC Ceiling Printing Machine

Two-Color Printing Unit

The two-color printing unit is responsible for transferring decorative patterns onto PVC ceiling and wall panels.

Different printing cylinders can be selected for wood-grain, marble-effect, and customized patterns.

Key Functions:

  • Two-color decorative printing

  • Replaceable printing cylinders

  • Different ink colour combinations

  • Adjustable printing operation

  • Optional servo printing

Ink Supply System

The ink supply system uses diaphragm pumps to feed printing ink continuously.

Suitable collection and recovery arrangements help maintain material circulation and reduce unnecessary handling during operation.

UV Roller Coating Unit

The UV coating unit applies varnish to the printed panel surface.

Independently driven coating rollers allow operators to adjust coating operation for different varnishes and surface requirements.

The coating system supports glossy and matte decorative finishes when used with suitable UV formulations.

UV Curing System

UV curing is used to cure compatible UV varnishes after coating.

Curing equipment and operating conditions should be matched to the selected coating formulation, panel dimensions, and conveying speed.

Conveyor and Control System

The conveyor transports panels through the printing and coating sections.

Adjustable speed control allows operators to coordinate panel movement with the printing and coating processes.

Frequently Asked Questions

What is a PVC ceiling printing machine?

A PVC ceiling printing machine applies decorative patterns onto PVC ceiling panels using printing cylinders and suitable inks. A combined printing and UV coating line also applies varnish to create the required finished surface.

Can the machine print wood-grain and marble patterns?

Yes. ANDA's two-color printing system supports wood-grain, marble-effect, and other decorative patterns using suitable printing cylinders.

Can the machine produce glossy and matte finishes?

Yes. Different UV coating formulations and operating conditions can be selected to achieve glossy or matte decorative finishes.

What is the maximum production speed?

The specified conveying speed is up to 30 m/min. Actual production speed depends on panel dimensions, ink, coating materials, and process requirements.

Can the printing patterns be changed?

Yes. Printing cylinders can be changed to produce different decorative patterns, and suitable ink colours can be selected according to the required design.

What is the difference between Model 600 and Model 800?

The models have different published power ratings. Their exact working widths and final equipment configurations should be confirmed with ANDA before ordering.

Can ANDA customize the printing and UV coating line?

ANDA can discuss printing colours, cylinder configurations, optional servo printing, and other equipment requirements according to the customer's production needs.
