PVC Edge Band Calender Machine
Our PVC Edge Band Production Line with Calender Cooling is a fully automated integrated equipment specially developed to produce PVC edge bands of different widths, thicknesses and cross-sectional shapes. The line adopts a scientific combination of conical twin-screw extrusion, three-roller calendering and efficient cooling, which realizes continuous and stable production from raw material mixing to finished product winding. The surface of the produced PVC edge band can be further processed by three-color printing, glossy oil coating or heat transfer printing to meet diverse aesthetic and functional needs of customers. It is an ideal production equipment for enterprises engaged in PVC edge band processing, helping to improve production efficiency, reduce labor costs and enhance product competitiveness.
PVC edge band production line with Calender Cooling is used to produce PVC edge band with different width, section shape and thickness. The surface of PVC edge band can be treated by three color printing & coated with glossy oil, or by heat transfer printing.PVC edge band production line with Calender Cooling is used to produce PVC edge band with different width, section shape and thickness. The surface of PVC edge band can be treated by three color printing & coated with glossy oil, or by heat transfer printing.
The production line is composed of high-quality core components, each of which is precision-manufactured and strictly tested to ensure stable operation and long service life. The working principle is scientific and efficient, realizing the whole process of automated production with minimal manual intervention:
Model | 160 | 400 | 750 |
Extruder | 51/105 | 55/110 | 65/132 |
Max Width | 160mm | 400mm | 750mm |
Main Motor Power | 18.5kw | 22kw | 37kw |
Special requirement can be customized | |||
Main Features:
High output: one PVC edge band sheet can be cut into 15 or so strip of edge band.
High quality: it could fit the demanded thickness and flatness.
Save labors: highly automatic could achieve the process from extruding to cutting and rolling.
Famous Brand Parts: ABB frequency converter, PID control, Siemens Motor and so on.
Conical Twin-Screw Extruder: Equipped with Siemens motor and ABB inverter, with high torque gearbox and bimetallic screw & barrel (material: 38CrMoALA), which ensures uniform plasticization of PVC raw materials, high extrusion efficiency and stable output. The main models include SJSZ 55/110 and SJSZ 65/132, which can be selected according to production capacity needs.
Three-Roller Calender System: The rollers have high processing accuracy and good surface smoothness, which can effectively shape the extruded PVC material, ensuring the flatness, thickness uniformity and surface gloss of the edge band. The roller spacing can be flexibly adjusted to adapt to different product specifications.
Efficient Calender Cooling Device: Adopts water cooling method, which can quickly cool and solidify the calendered PVC edge band, effectively improving production efficiency while ensuring the physical properties and dimensional stability of the product. The cooling temperature can be intelligently adjusted according to production needs.
Intelligent Control System: Equipped with PLC control and human-machine interface (HMI), which realizes automatic control of each link such as raw material transportation, extrusion, calendering, cooling, traction and winding. The operation is simple and intuitive, and parameters can be adjusted in real time to reduce manual errors.
Auxiliary Components: Including raw material mixer, traction machine, primer machine, cutting machine, automatic stacker and winder. The automatic stacker saves labor costs, and the winder adopts tension control system to ensure smooth winding of finished products.
Furniture Industry: Used for edge banding of various furniture such as cabinets, wardrobes, desks and tables, which can protect and reinforce the board, improve the appearance and texture of furniture, and enhance the environmental performance of furniture by preventing formaldehyde emission.
Building Materials Industry: Applied to edge banding of decorative boards such as particle board, density board, block board and plywood, which is suitable for interior decoration, office decoration and commercial space decoration.
Other Fields: Used for edge banding of door edges, laboratory cabinets, teaching equipment and kitchen utensils, providing protection and decoration functions.
