PVC Door Board Making Machine

The PVC Door Board Making Machine is designed to manufacture rigid PVC door boards through a continuous extrusion process. Available in YF700, YF800 and YF900 configurations, it supports maximum board widths of 700 mm, 800 mm and 1000 mm, with production capacity of up to 10,000 kg per day. The machine provides stable extrusion, precise temperature control and flexible configuration options for PVC door board manufacturers.

Availability:

Quantity:



Inquire Add to Basket

国家:
China
YANSE:
JINSE

Product Overview

The PVC Door Board Making Machine is designed to manufacture rigid PVC door boards for interior doors and related door applications. The machine uses a PVC extrusion process to produce door boards in different widths according to the selected configuration.

Anda offers three main configurations, including YF700, YF800 and YF900. The corresponding extruders are 65/132, 80/156 and 92/188, with maximum applicable board widths of 700 mm, 800 mm and 1000 mm respectively.

With a suitable configuration, the machine can achieve a production capacity of up to 10,000 kg per day, equivalent to approximately 400–500 door boards per day, depending on product specifications and operating conditions.

Key Features of PVC Door Board Making Machine

Multiple Width Options: Supports maximum applicable widths of 700 mm, 800 mm and 1000 mm.
Three Machine Configurations: Available with 65/132, 80/156 and 92/188 extruders.
High Production Capacity: Capacity can reach up to 10,000 kg/day under suitable production conditions.
Stable Extrusion: The extrusion system provides continuous processing for rigid PVC door boards.
Reliable Electrical Components: The machine uses branded inverters, contactors and temperature controllers.
Precise Temperature Control: The temperature control system helps maintain stable processing conditions.
Suitable for Door Board Manufacturing: Designed specifically for producing PVC door boards for interior applications.

PVC Door Board Making Machine Specifications

Parameter	YF700	YF800	YF900
Extruder	65/132	80/156	92/188
Maximum Applicable Width	700 mm	800 mm	1000 mm

The maximum applicable width refers to the board width supported by each machine configuration. The final product specifications should be confirmed according to the selected die, material formulation and production requirements.

Main Components of the PVC Door Board Making Machine

PVC Extruder

The extruder is the main processing unit of the machine. Anda provides three configurations:

65/132 extruder
80/156 extruder
92/188 extruder

The selected extruder is matched with the required door board width and production requirements.

Die

The die forms the extruded PVC material into the required door board profile. Die configuration is an important factor when determining the final board width and profile design.

Cooling and Calibration System

The cooling section stabilizes the extruded board after it leaves the die. It helps maintain dimensional consistency during continuous production.

Hauling Machine

The hauling machine pulls the formed board through the production process at a controlled speed. Stable hauling helps maintain consistent board dimensions.

Cutting Machine

The cutting system cuts the continuous PVC door board into predetermined lengths for further handling.

Stacker

The stacker collects finished door boards after cutting, reducing manual handling during production.

Electrical and Control Components

The PVC Door Board Making Machine is equipped with branded electrical components designed for stable machine operation.

Frequency Inverter

A branded inverter is used to control machine operation and support stable production.

Contactor

The machine uses branded contactors for reliable electrical switching and control.

Temperature Controller

The temperature controller provides precise temperature management during PVC processing. Stable temperature control is important for maintaining consistent extrusion conditions.

Production Capacity

The PVC Door Board Making Machine can achieve a capacity of up to 10,000 kg/day under suitable production conditions.

This production capacity is equivalent to approximately 400–500 door boards per day, depending on factors such as:

Door board width
Board thickness
Product weight
Material formulation
Extrusion speed
Operating schedule
Machine configuration

Therefore, actual production output should be calculated according to the customer's target product specifications rather than using the maximum capacity as a fixed output.
