Twin screw PVC edge banding tape machine is used to produce PVC edge band, it's widely used for edge sealing of MDF, HDF, particle board, composite board and so on.
Twin screw PVC edge banding tape machine is used to produce PVC edge band which is popular used for the cross section of furniture plate for protection, decoration. We can make the size of 19-100mm width and 0.4-2mm thickness. The surface of PVC edge band is treated by printing. By switching printing roller, the surface of PVC edge band can get different design.
We can use single screw extruder or double screw extruder to produce PVC edge band according to customer requirement.
Main parameter of twin screw PVC edge banding tape machine
Model | SJSZ45 | SJSZ55 |
Extruder | 45/100 | 55/110 |
Output Cavities | 2 cavity | 4 cavity ,6 cavity or 8 cavity |
Capacity | 1.5-1.8 ton per day | 2.2 tons per day |
High-Precision Printing Head: Equipped with imported industrial printing head (Epson/DX5), featuring high resolution (up to 1440dpi) and fast printing speed, which can realize precise printing of fine patterns and small characters, ensuring clear and delicate printed patterns without burrs. The printing head adopts anti-clogging design, which is easy to maintain and can effectively extend the service life.
Intelligent Positioning System: Adopting automatic photoelectric positioning and deviation correction device, with high positioning accuracy (error ≤ 0.1mm), which can effectively avoid printing deviation caused by uneven feeding of PVC edge bands. It is equipped with automatic color mark detection function, which can automatically adjust the printing position according to the edge band specifications, ensuring consistent printing effect of each batch of products.
Efficient Drying System: Equipped with infrared and hot air circulation dual drying device, which can quickly dry the printed ink in a short time (drying time ≤ 3 seconds), effectively avoiding ink smearing and fading, and ensuring the adhesion and wear resistance of the printed surface. The drying temperature can be intelligently adjusted (30-80℃) according to the ink type and printing speed, adapting to different production needs.
Automatic Feeding & Winding System: The feeding system adopts adjustable tension control, which can adapt to PVC edge bands of different widths (10-60mm) and thicknesses (0.3-6mm), avoiding edge band deformation and surface scratch during feeding. The winding system adopts automatic tension adjustment and neat winding design, which can directly wind the printed edge bands into rolls, reducing manual sorting and improving production efficiency.
Intelligent Control Panel: Equipped with PLC control system and 7-inch touch screen HMI, the operation is simple and intuitive. It can pre-store multiple printing parameters (pattern, speed, temperature, etc.), and support one-key call, which is convenient for batch production. It is equipped with fault alarm and self-diagnosis function, which can quickly locate equipment faults and reduce maintenance time.
Environmentally Friendly Ink Supply System: Adopting closed ink supply system, which can effectively prevent ink volatilization and waste, and is equipped with ink level detection function, which can remind users to add ink in time. The supporting special ink for PVC has the advantages of non-toxic, environmentally friendly, fast drying and strong adhesion, complying with international environmental protection standards (ROHS, REACH).
