FM Series Cold Glue PVC Fluted Wall Panel Lamination Machine

Product Overview:
ANDA's Cold Glue PVC Fluted Panel Lamination Machine is designed to apply decorative PVC films and papers to PVC fluted wall panels, WPC panels, decorative profiles, and other compatible substrates.
The machine combines film unwinding, photoelectric tracking, film tension control, surface cleaning, adhesive coating, and roller pressing to support decorative surface lamination.
Key Features:
Cold Glue Lamination: Designed for adhesive-based decorative film and paper lamination.
Multiple Panel Types: Suitable for PVC fluted panels, WPC wall panels, PVC profiles, and compatible boards.
Dual Film Unwinding: Supports convenient decorative film feeding.
Photoelectric Film Tracking: Helps maintain film alignment during lamination.
Film Tension Control: Supports stable film feeding and positioning.
Flexible Glue Application: Roller coating and scraping coating arrangements are available according to requirements.
Two Machine Models: FT400 and FT600, with maximum working widths of 400 mm and 600 mm.
Availability:
Quantity:
Inquire Add to Basket

  • China

  • JINSE

Key Features and Benefits

Designed for Decorative Fluted Panels

The machine is suitable for applying decorative films to PVC fluted wall panels and compatible WPC profiles.

It supports decorative surface finishing for panels used in interior wall applications.

Flexible Cold Glue Application

The cold glue system supports different adhesive coating arrangements.

Roller coating and scraping coating options allow manufacturers to select a suitable application method for their materials.

Accurate Film Positioning

Photoelectric tracking and film tension control help maintain film alignment throughout the lamination process.

This is useful when working with patterned decorative films.

Adaptable Pressing Roller Arrangement

Different profile shapes may require different pressing roller arrangements.

ANDA's FM Series is designed to accommodate various profile configurations through suitable roller selection and adjustment.

Dual Film Feeding Design

The dual unwinding arrangement provides flexibility in decorative film handling.

The final feeding setup can be selected according to production requirements.

Two Working Width Options

FT400 and FT600 models provide maximum working widths of 400 mm and 600 mm.

Customers can choose a suitable model based on their panel dimensions.

Compatible Materials and Applications

The FM Series Cold Glue Lamination Machine can be configured for different decorative panel and profile applications.

PVC Fluted Wall Panels

Apply compatible decorative films to PVC fluted panels for interior wall decoration.

WPC Wall Panels

Laminate decorative surface materials onto suitable WPC wall panels and profiles.

PVC Decorative Profiles

Process compatible PVC decorative profiles, including applications that require a shaped pressing roller arrangement.

PVC Boards and Windowsills

Apply decorative films or papers to suitable PVC boards and windowsill products.

MDF and Other Compatible Boards

The machine may also be configured for MDF and other board substrates when the adhesive and surface materials are suitable.

Technical Specifications

The FM Series is available in two models for different panel widths and production requirements.

Parameter

FT400

FT600

Maximum Working Width

400 mm

600 mm

Workpiece Thickness

2–80 mm

2–80 mm

Total Power

6.5 kW

10 kW

Machine Weight

2,500 kg

3,000 kg

Machine Dimensions (L × W × H)

4500 × 1000 × 2200 mm

6000 × 1200 × 2200 mm

Specifications are based on ANDA's published product information. Working speed, adhesive compatibility, roller configuration, and final machine specifications should be confirmed before ordering.

Cold Glue Lamination vs. PUR Hot Melt Lamination

Cold glue and PUR hot melt lamination use different adhesive application processes.

Comparison

Cold Glue Lamination

PUR Hot Melt Lamination

Adhesive System

Compatible cold-applied adhesive

Heated PUR hot melt adhesive

Adhesive Application

Coating system selected for adhesive formulation

PUR melting and application system

Bonding Process

Depends on adhesive chemistry and drying or curing conditions

Depends on PUR application and moisture-curing conditions

Machine Selection

Based on film, substrate, adhesive, and panel geometry

Based on PUR compatibility and production requirements

Typical ANDA Product Focus

PVC fluted panels and decorative profiles

PUR flat lamination and profile wrapping

The best process depends on the substrate, decorative film, adhesive formulation, required bond performance, and production conditions.

How to Choose the Right Cold Glue Lamination Machine

Before selecting an FM Series machine, consider the following requirements.

Selection Factor

Information to Provide

Panel Type

PVC fluted panel, WPC panel, PVC profile, or other substrate

Panel Width

Required maximum working width

Panel Thickness

Thickness within the supported 2–80 mm range

Panel Geometry

Flat, fluted, grooved, or shaped cross-section

Decorative Material

PVC film, decorative paper, or another compatible material

Adhesive Type

Cold glue formulation and bonding requirements

Coating Method

Roller coating or scraping coating

Production Requirements

Target working speed and desired machine configuration

For fluted or shaped panels, providing a cross-sectional drawing helps determine the appropriate pressing roller arrangement.

Main Components of the Cold Glue Lamination Machine

Dual Film Unwinding System

The dual film unwinding system supplies decorative films to the lamination section.

A pneumatic expanding shaft helps secure film rolls during operation and supports suitable film tension.

Photoelectric Film Tracking System

The photoelectric tracking system helps monitor and correct film positioning during production.

Proper alignment is particularly important when applying decorative patterns to fluted wall panels and other shaped surfaces.

Film Tension Control System

The film tension control system helps maintain consistent film feeding during lamination.

Stable film tension supports accurate material positioning and reduces unnecessary film movement.

Surface Cleaning Device

The cleaning device removes loose dust and surface contaminants before adhesive application.

A suitable substrate surface helps support consistent bonding between the decorative film and panel.

Cold Glue Coating System

The adhesive coating system applies glue to the selected surface according to the machine configuration.

ANDA offers different coating arrangements, including roller coating and scraping coating options.

The appropriate method depends on the adhesive formulation, decorative material, and substrate requirements.

Roller Pressing and Lamination Section

The pressing section brings the decorative material into contact with the panel surface.

For fluted panels and decorative profiles, the pressing rollers must be arranged to match the panel geometry.

Suitable roller adjustment helps the film follow the required surface contours.

Frequently Asked Questions

What is a cold glue PVC fluted panel lamination machine?

It is a surface-finishing machine that applies decorative films or papers to PVC fluted panels using a compatible cold-applied adhesive and pressing system.

What materials can the FM Series machine process?

The published application range includes PVC boards, MDF, WPC boards, PVC profiles, windowsills, and PVC/WPC wall panels. Final compatibility depends on the machine configuration and adhesive system.

What is the difference between cold glue and PUR hot melt lamination?

Cold glue lamination uses an adhesive applied without a PUR hot melt heating process. PUR hot melt lamination requires a dedicated heated adhesive system. The suitable method depends on the materials and bonding requirements.

Can the machine laminate PVC fluted wall panels?

Yes. PVC fluted wall panels are a primary application of this FM Series machine. Pressing roller arrangements should be selected according to the panel's cross-sectional shape.

What decorative materials can be used?

The published machine description includes PVC decorative films and decorative papers. Other materials should be evaluated for adhesive and equipment compatibility.

What is the maximum working width?

The FT400 model supports a maximum working width of 400 mm, while FT600 supports up to 600 mm.

Does the machine have film tracking control?

Yes. The published configuration includes a photoelectric film tracking system and automatic film extension control.

Are different glue coating methods available?

Yes. ANDA lists roller coating and scraping coating arrangements as available options. The final coating system should be selected according to the adhesive and application.

Can the pressing rollers be customized?

Different panel and profile shapes may require different roller arrangements. Customers should provide profile drawings and material specifications so ANDA can confirm the suitable configuration.

What information is needed for a quotation?

Please provide the panel material, width, thickness, cross-sectional drawing, decorative film type, adhesive requirements, and target production speed.
